Description
The Husqvarna Z500 series zero turn mower represents the latest design focused on productivity, durability and cut quality. Providing extreme comfort, high ground speeds and superior traction adds up to exceptional mowing efficiency. Industrial strength throughout the entire design assures a long & durable service life in commercial mowing applications. Careful design consideration provides unprecedented ease in serviceability.
-
Motor/engine manufacturer – Kawasaki
-
Horsepower – 31 hp
-
Cutting width – 60 in
-
Productivity – 5.8 acres/hr
Premium suspension seat
Heavily bolstered cushions provide all day comfort for the operator. Combined with a dial by weight full suspension seat, the Z500X series provides extreme comfort under the most adverse situations
Automatic parking brake
The new patent pending parking brake system automatically activates or deactiates as the steering levers are moved outward or inward.
Large fuel capacity
Twelve gallons of fuel capacity for all-day cutting capability.
LED fuel gauge
The automotive style LED fuel gauge lets you know exactly how much fuel is remaining and warns you when you are too low.
Capacity
Productivity – 23471.8 m²/h
Speed forward max – 19.3 km/h
Speed forward min – 0 km/h
Speed forward max – 19.3 km/h
Speed forward min – 0 km/h
Cutting deck
Cutting width – 60 in
Cutting width – 152.4 cm
Cutting deck type – 7-gauge fabricated
Cutting methods – Collect/Mulch/Side discharge
Cutting deck material – Steel
Deck thickness – 4.76 mm
Cutting height steps – 16
Blade engagement – Electric clutch
Clutch rating – 338.95 Nm
Blades – 3 pcs
Blade-tip speed – 93.98 m/s
Anti-scalp wheels – 4
Nose roller – Yes
Deck lifting system – Manual, foot assisted
Powder-coated cutting deck – Yes
Spindle/mandrel type – Cast iron
Greasable mandrels – Yes
Deck Wash Port – No
Cutting height max – 127 mm
Cutting height min – 25.4 mm
Cutting width – 152.4 cm
Cutting deck type – 7-gauge fabricated
Cutting methods – Collect/Mulch/Side discharge
Cutting deck material – Steel
Deck thickness – 4.76 mm
Cutting height steps – 16
Blade engagement – Electric clutch
Clutch rating – 338.95 Nm
Blades – 3 pcs
Blade-tip speed – 93.98 m/s
Anti-scalp wheels – 4
Nose roller – Yes
Deck lifting system – Manual, foot assisted
Powder-coated cutting deck – Yes
Spindle/mandrel type – Cast iron
Greasable mandrels – Yes
Deck Wash Port – No
Cutting height max – 127 mm
Cutting height min – 25.4 mm
Dimensions
Base machine, length – 206 cm
Base machine, height – 117 cm
Base machine, width (chute down) – 188 cm
Base machine, width (chute up) – 161.9 cm
Weight – 594 kg
Base machine, height (ROPS down) – 117 cm
Base machine, height (ROPS up) – 185 cm
Base machine, height – 117 cm
Base machine, width (chute down) – 188 cm
Base machine, width (chute up) – 161.9 cm
Weight – 594 kg
Base machine, height (ROPS down) – 117 cm
Base machine, height (ROPS up) – 185 cm
Drive system
Transmission type – Hydrostatic
Transmission manufacturer – Hydro-Gear
Transmission model – ZT 5400
Pump displacement – 16 cm³
Fan-cooled pumps – Yes
Transmission manufacturer – Hydro-Gear
Transmission model – ZT 5400
Pump displacement – 16 cm³
Fan-cooled pumps – Yes
Engine
Motor/engine manufacturer – Kawasaki
Engine name – FX Series
Cylinder displacement – 999 cm³
Cylinders – 2
Engine cooling – Air
Air filter type – Dual element canister filter
Power/fuel type – Gasoline
Engine lubrication type – Full pressure
Oil filter – Yes
Fuel tank volume (with reserve) – 45.4 l
Fuel tank location – Side (Dual)
Engine name – FX Series
Cylinder displacement – 999 cm³
Cylinders – 2
Engine cooling – Air
Air filter type – Dual element canister filter
Power/fuel type – Gasoline
Engine lubrication type – Full pressure
Oil filter – Yes
Fuel tank volume (with reserve) – 45.4 l
Fuel tank location – Side (Dual)
Equipment
Seat material – Vinyl
Seat spring – Yes
Seat back height – High
Hour meter type – Yes
Cup holder – Yes
Armrests – Yes
ROPS – Yes
Seat type – Professional, suspension
Seat spring – Yes
Seat back height – High
Hour meter type – Yes
Cup holder – Yes
Armrests – Yes
ROPS – Yes
Seat type – Professional, suspension
